This tilt column is designed for use with floor shifter. They feature a 2" tube diameter and compact shroud create a unique new custom look. Each column comes complete with a stainless steel dress up kit (Tilt/turn signal levers and hazard knob), GM wiring (4-1/4in. connector) and an all new canceling cam. Shaft size is 1 in. DD.

This isn't a rebuilt junkyard column, but rather an all new Flaming River engineered column featuring all new components. Made in the USA.

All Flaming River columns are made from 304 grade stainless steel, in paintable mill finish OR polished to a high luster. They will never rust and are chemically clean and can be painted to match or highlight an interior with only minor preparation.

  Billet-Joint Universal Joint

The Billet-Joint Universal joint are CNC machined from aircraft steel to precision tolerances. The sealed needle bearing design will last ten times longer than a standard pin and block universal joint. The unique nickel plating prevents rust without the hassle of painting. Polishing available for a "stainless look" at a nominal charge. Quality at an affordable price.

• Sealed Needle bearing design
• CNC Machined from aircraft billet steel
• Electroless Nickel Plated for corrosion resistance

Column Shift Tilt Column

Flaming River now manufactures an all new column shift style of tilt column. Featuring a sleek, compact design, the column shift is ideal for Hotrods, Pick Up Trucks, Classics and infinite other applications. All new components have been engineered by Flaming River to incorporate state-of-the-art technology in this nostalgic design. Each column comes complete with gearshift knob, stainless steel dress up kit (tilt, turn signal levers and hazard knob), illuminated gearshift indicator and GM wiring (4-1/4 in. connector) and removable 12-position linkage arm. Shaft size is 1 in. DD. 2" tube diameter. Combination Neutral Safety Switch/Back up light available, must be ordered with column.

Have an Overdrive transmission? No problem, order the optional Overdrive lens , part number FR20010LNO.

All Flaming River columns are made from 304 grade stainless steel, in paintable mill finish OR polished to a high luster. They will never rust and are chemically clean and can be painted to match or highlight an interior with only minor preparation.

Steel Steering Shafts - Plated

There are two types of intermediate shaft systems: DD or Splined. Either shafting is ideal for your steering system. Splined shafts allow a more precise adjustments. DD can only be phased 180 while splined shafts can be rotated fractionally. The advantage to DD, however, is that it can be cut to any length eliminating the need to premeasure. You will need to choose which shafting you will be using prior to ordering the universal joints, since one side accommodates the shaft.

Manufactured using a pre-ground alloy steel for strength and cosmetics. Splined shafts are available with electroless nickel plating for corrosion resistance. Shafts are manufactured in 2" increments: 4"-36" lengths. Splined 2 inches on each side. This allows for up to 2 inches of total trim.


Stainless Steel Shafts (polished and unpolished) also available.
